Product Parameters
| Product model | CCNB6.5KW-8KWH | CCNB6.5KW-16KWH | CCNB6.5KW-24KWH | CCNB6.5KW-32KWH | CCNB6.5KW-40KWH |
| Rated power | 6.5KW | ||||
| Phase number | 单相 | ||||
| Rated voltage |
51.2V |
||||
| Rated capacity of battery | 156AH | ||||
| Continuous discharge current |
150A |
||||
| Maximum discharge current | 200A<3s | ||||
| Standard charging current | 0.2C/31.2A | ||||
| Fast charging current | 0.5C/78A | ||||
| Number of battery configurations | 2 | 3 |
4 |
5 | |
| Battery type | 锂铁电池(LiFePO4) | ||||
| cycle life | ≥2500次 | ||||
| Battery voltage range | 40~58.4V | ||||
| Input voltage range of mains power | 市电模式90~280VAC;UPS:170~280Vac | ||||
| Rated frequency of mains power input | 50Hz/60Hz自适应 | ||||
| Maximum recommended component power |
6000W |
||||
| Component open circuit voltage |
450V |
||||
| MPPT working voltage range | 120~430V | ||||
| Charging and discharging efficiency |
94% |
||||
| working temperature | -0~45℃ | ||||
| Storage temperature | -20~60℃ | ||||
| Working humidity | ≤95% | ||||
| Heat dissipation method | 风冷 | ||||
Application Scenarios
